B95W
Transport
08_Transport_en.fm - V1.0 - 1.8.17
269 / 306
8
27
8.4 Transporting the machine
Fig. 8-7 Lashing for transport
1 Possible rigging points
To transport the machine on a flat bed trailer, railway goods wagon, etc., the
following measures must be taken:
Securing the machine
Depose the support legs (and/or dozer blade) and the working equipment on
the ground.
Shut down the engine.
Lash the machine down with straps at the marked points.
Secure the machine with wheel chocks against rolling.
Risk posed by excessive width / height
Risk of serious injury with fatal consequences.
Z Pay attention to the overall dimensions for transport.
Z Pay attention to clearance heights for tunnels, bridges, etc.
6300
2930
1
< 2500
