Tab. 9-10 Hydraulics
9.2.9 Axles
Tab. 9-11 Axles
Steering B95W AL Electrically preselectable steering mode
Fully-hydraulic, proportionally jointed front and rear axle,
by means of a steering control device and a steering
cylinder integrated in the axles
The following steering variants are possible through the
two steerable axles:
Normal steering mode: normal steering mode for driving in the street and
regular work - only the front axle turns.
All-wheel steering “round”: this steering mode reduces the turning circle.
Both axles steer in opposition.
All-wheel steering “crab”: this steering mode enables lateral movement
Both axles steer in the same direction.
Wheel deflection max. 30°
Axles
Front axle B95W, B95W AL
Steering planet drive axle with oscillating suspended
transmission, with 2 multiple disk brakes running in oil bath
in center housing and integrated steering cylinder
• Oscillation ± 6,5°
B95W S
Steering planet drive axle with two-stage, switchable
oscillating suspended transmission, with two multiple disk
brakes running in oil bath in center housing and integrated
steering cylinder
• Oscillation ± 6,5°
Rear axle B95W, B95W S
Planet drive axle with 2 multiple disk brakes running in oil
bath in the hub
B95W AL
Steering planet drive axle with two multiple disk brakes
running in oil bath in center housing and integrated steering
cylinder
Hydraulics
