B95W
Maintenance
200 / 306
6
06_Wartung und Pflege_en.fm - V1.0 - 1.8.17
20
6.7.21 Windshield wash/wipe system
The windshield washer fluid tank is located under the side hood of the diesel
tank and hydraulics system. It can be accessed when the cover is raised.
Topping up the windshield wash/wipe system
.
Fig. 6-43 Windshield washer tank
1 Diesel tank/hydraulic system cover
2 Reservoir
3 Maintenance ladder
Open maintenance cover to the right, unlock locking strap and lodge.
Unlock and fold down maintenance ladder (3).
Open the diesel tank/hydraulics system cover (1).
Fill up the washing water reservoir (2) as required.
Add antifreeze when temperatures are around or below freezing.
Close the diesel tank/hydraulics system cover.
When folding up the maintenance ladder and cover, ensure that the locks are
locked into place.
Notice
Fold down/fold up maintenance ladder. See chapter 6.7.5 “Fuel system”.
