6.5.1 Lubrication schedule
Overview of lubricating points
Fig. 6-2 Lubrication schedule
Grease all lubricating points with multi-purpose grease
Danger due to heavy load
Machine parts may move unexpectedly.
Risk of serious injuries with fatal consequences.
Z To lubricate the quick-attach system: Place the dipper on the
ground, open the quick-attach system (the pins must be fully
retracted), and apply lubricant. Then close the quick-attach
system.
