3.3.2 Pictograms
The following pictograms may be attached to the machine:
Pictogram Description Pictogram Description
Battery charge
indicator
Monitoring
pre-heating
Engine oil pressure Engine oil level
Fuel Fuel level
Hydraulic oil Hydraulic oil level
Coolant temperature
Hydraulic oil filter
clogging indicator
Heating/ventilation
blower
Windshield wiper
wash/wipe system
Operating hours
counter
Potentiometer
Working lights Air filter indicator
Rotating beacons Hydraulic hammer
Dozer blade Working hydraulics
shut-off
Float position dozer
blade
OFF switch overload
warning device
Travel speed SLOW Travel speed FAST
Hydraulic quick-attach
system
Auto-idling system
- +
,
