B95W
Operation
220 / 306
7
07_Bedienung_en.fm - V1.0 - 1.8.17
26
Driving with the gas pedal (on roads and off-road)
Start Up
Fig. 7-7 Travel
1 Apportionable driving
2 Service brake/excavator brake
3 Accelerator pedal
4 Move forwards/backwards
5 Engine speed setting (manual throttle)
6 Right-hand support
7 Left-hand support
Engage the parking brake.
Put the selection lever for the direction of travel (4) into neutral.
Start the engine.
Put the manual throttle (5) into idle position.
Move the outrigger upwards (6, 7).
Select driving setting 1 (slow) or 2 (fast).
J The driving setting selected will be shown on the display.
Danger due to heavy load
Machine may move unexpectedly.
Danger of serious injuries with fatal consequences.
Z When driving the machine with the foot throttle, always put
the manual throttle into the idle position.
13
4
5
6
7
2
