B95W
Operation
07_Bedienung_en.fm - V1.0 - 1.8.17
229 / 306
7
26
Rotate the uppercarriage into the drive position (message on display).
Raise the boom up to the mark on the slewing column. If there is no mark,
simply raise the boom as high as it will go.
Move the working device into transport position using the backsight (1).
Retract the intermediate boom cylinder fully.
Put the dipperstick into a horizontal position so that the colored marking (3)
above the dipperstick aligns with the underside of the intermediate boom.
Rotate the bucket in accordance with the colored marking (4) above the tilt
control lever.
Rotate the ditch-cleaning bucket in accordance with the colored marking (4)
beneath the tilt control lever, position it horizontally and lock it to prevent it
from swaying.
Retract the support legs fully and secure the support plates mechanically with
the chain.
Move the support plate (optional) fully upwards and attach the removable
rear reflector.
Move the front dozer blade (optional) fully upwards.
Switch off the working hydraulics and all-wheel drive on the keypad.
While driving on roads, the switch for the oscillating axle locking and direction
reverser must be set to “OFF”.
J The control lights in the switch are off.
Put the manual throttle into the idle position.
Attach lighting unit on bucket cylinder (2) and connect to the socket (on upper
carriage, in front, next to cab) (only as required, e.g. in case of poor visibility,
darkness, etc).
Check the function of the direction indicators, hazard warning lights, horn,
low/high beam.
Close the cab door.
Notice
With clamshell grabs attached, the grab must be suspended on the pincer
tube (6) and closed. The position of the dipperstick must be adjusted.
