B95W
Technical data
09_Technische Daten_en.fm - V1.0 - 1.8.17
273 / 306
9
29
Circular boom
Fig. 9-3 Digging envelope - circular boom
A 3340mm with 600 bucket
B 3500mm with 800 bucket
C 3500mm with 600 bucket
D 3570mm with 800 bucket
