Articulated boom with dipperstick 2000
Articulated boom with dipperstick 2000 mm and additional rear weight
Load distance from middle of slewing ring
Bucket hinge pin
height
3 m 4 m 5 m 6 m 7 m
longitu-
dinal
lateral longitu-
dinal
lateral longitu-
dinal
lateral longitu-
dinal
lateral longitu-
dinal
lateral
3.0 m A--
2.6 2.3 1.7 1.6 1.5 1.0 - -
V--
2.2 2.2 1.6 1.6 1.0 1.0 - -
1.5 m A
4.1 3.5 2.6 2.3 2.1 1.6 1.5 1.0 - -
V
3.4 3.3 2.2 2.2 1.3 1.5 0.9 1.0 - -
0.0 m A
4.5 2.7 2.7 1.8 2.0 1.3 1.5 0.9 - -
V
2.6 2.6 1.7 1.7 1.2 1.2 0.9 0.9 - -
-1.0 m A
4.7 2.7 2.9 1.7 2.0 1.2 - - - -
V
2.6 2.6 1.6 1.7 1.2 1.2 - - - -
Load distance from middle of slewing ring
Bucket hinge pin
height
3 m 4 m 5 m 6 m 7 m
longitu-
dinal
lateral longitu-
dinal
lateral longitu-
dinal
lateral longitu-
dinal
lateral longitu-
dinal
lateral
3.0 m A
- - 2.6 2.4 1.8 1.7 1.5 1.1 - -
V
- - 2.4 2.3 1.7 1.7 1.1 1.1 - -
1.5 m A
4.2 3.7 2.6 2.3 2.1 1.7 1.6 1.1 - -
V
3.6 3.7 2.3 2.3 1.7 1.6 1.1 1.1 - -
0.0 m A
4.7 2.9 2.8 1.9 2.1 1.4 1.6 1.0 - -
V
2.8 2.9 1.8 1.9 1.3 1.4 1.0 1.0 - -
-1.0 m A
4.8 2.9 3.0 1.9 2.1 1.4 - - - -
V
2.8 2.8 1.8 1.9 1.3 1.4 - - - -
