B95W
Description
05_Beschreibung_en.fm - V1.0 - 1.8.17
59 / 306
5
11
All electrical components are accessible by:
• Opening the maintenance cover on the diagnostic interface
• Opening the side/maintenance cover and folding out the maintenance steps
and removing the maintenance cover on the fuses and relays
• Opening the engine hood
The generator supplies the onboard power supply system with a voltage of 12 V.
You can disconnect the entire machine from the power supply with the main
battery switch, e. g. for maintenance work.
Notice
The control unit will remain active another 40 seconds or so to save the
system data and then it will turn itself off.
This process can last up to 2 minutes for engines with an SCR system, given
that the SCR lines need to be out in this time.
For this reason, the engine’s power supply must not be suddenly interrupted
via the isolator switch.
