B95W
Description
05_Beschreibung_en.fm - V1.0 - 1.8.17
71 / 306
5
11
Engine
monitoring
icons
Tab. 5-5 Engine monitoring pictograms
Machine
monitoring
icons
Tab. 5-6 Machine monitoring icons
Notice
If several pieces of information are being provided simultaneously, the
display of the multi-icon error symbols changes every 5 seconds.
Sym-
bol
Description Sym-
bol
Description
Engine oil pressure
Battery charge indicator
Pre-heating
Multi-icons (bottom right)
Engine diagnostics Condensed water in the fuel
filter
Coolant level Air filter maintenance
Particle-filter regeneration
(optional)
Ash lamp (optional)
AdBlue
®
particle filter
Sym-
bol
Description Sym-
bol
Description
Direction indicator
Trailer indicator light
Travel direction forward/reverse Neutral position direction of
travel
High beam
Park brake Accumulator pressure
Multi-icons (bottom right)
Hydraulic oil level Hydraulic filter
Multi-icons (bottom left)
Transmission neutral Transmission travel speed 1
Transmission travel speed 2
