User Parameter Tables
5-19
b5-13
PID
Feedback Loss
Detection
Level
Sets the PID feedback loss
detection level as a
percentage (%) of maximum
frequency (E1-04).
0
to
100
0% No A A A A A 1B1H
Fb los Det
Lvl
b5-14
PID
Feedback
Loss
Detection
Time
Sets the PID feedback loss
detection delay time in terms
of seconds.
0.0
to
25.5
1.0 s No A A A A A 1B2H
Fb los Det
Time
b5-15
PID Sleep
Function
Start level
Sets the sleep function start
frequency.
Note: Enabled even when
PID control mode has
not been selected.
0.0
to
400.0
0.0Hz No A A A A A 1B3H
PID Sleep
Level
b5-16
PID Sleep
Delay Time
Sets the sleep function delay
time in terms of 0.1 seconds.
0.0
to
25.5
0.0 s No A A A A A 1B4H
PID Sleep
Time
b5-17
PID
Accel/decel
Time
Applies an accel/decel time to
the PID setpoint reference. The
Drive's standard softstarter
(C1-xx and S-curve) still
affects the output of the PID
algorithm.
0.0
to
25.5
0.0 s No A A A A A 1B5H
PID Acc/Dec
Time
b5-18
PID
Setpoint
Selection
Allows the b5-19 setting to be
the PID target setpoint value.
0: Disabled
1: Enabled
0 to 1 0 No A A A A A 1DCH
PID
Setpoint Sel
b5-19
PID Setpoint
Sets the PID target value.
Use only when b5-18 = 1
0.0
to
100.0
0.0 % No A A A A A 1DDH
PID Setpoint
Parameter
Number
Name
Description
Setting
Range
Factory
Setting
Change
during
Operation
Control Methods
MODBUS
Register
Display
V/f
V/f
with
PG
Open
Loop
Vector
1
Flux
Vector
Open
Loop
Vector
2
