YASKAWA G7 Series User Manual

User Parameter Tables
5-29
Note The unit is set in o1-03 (frequency units of reference setting and monitor). The default for o1-03 is 0 (increments of 0.01Hz).
* Setting range changes to 0 thru 66.0 when operating in Vector 2 wo/PG. The upper limit for the setting range also depends on the upper limit in E1-04. The
max setting is 400.00.
d1-10
Frequency
Reference 10
Frequency reference when
multi-function input
"Multi-step speed reference 1, 4"
is ON. Setting units are
affected by o1-03.
0
to
400.00
*
0.00Hz Yes A A A A A 28BH
Reference 10
d1-11
Frequency
Reference 11
Frequency reference when
multi-function input
"Multi-step speed reference 2, 4"
is ON. Setting units are
affected by o1-03.
0.00Hz Yes A A A A A 28CH
Reference 11
d1-12
Frequency
Reference 12
Frequency reference when
multi-function input
"Multi-step speed reference 1, 2, 4"
is ON. Setting units are
affected by o1-03.
0.00Hz Yes A A A A A 28DH
Reference 12
d1-13
Frequency
Reference 13
Frequency reference when
multi-function input
"Multi-step speed reference 3, 4"
is ON. Setting units are
affected by o1-03.
0.00Hz Yes A A A A A 28EH
Reference 13
d1-14
Frequency
Reference 14
Frequency reference when
multi-function input
"Multi-step speed reference 1, 3, 4"
is ON. Setting units are
affected by o1-03.
0.00Hz Yes A A A A A 28FH
Reference 14
d1-15
Frequency
Reference 15
Frequency reference when
multi-function input
"Multi-step speed reference 2, 3, 4"
is ON. Setting units are
affected by o1-03.
0.00Hz Yes A A A A A 290H
Reference 15
d1-16
Frequency
Reference 16
Frequency reference when
multi-function input
"Multi-step speed reference 1, 2, 3, 4"
is ON. Setting units are
affected by o1-03.
0.00Hz Yes A A A A A 291H
Reference 16
d1-17
Jog
Frequency
Reference
Frequency reference when:
"Jog frequency reference" is
selected via multi-function
input terminals. "Jog
frequency reference" has
priority over "multi-step
speed reference 1 to 4".
Parameter d1-17 is also the
reference for the JOG key on
the Digital Operator, and the
multi-function inputs
"forward jog" and "reverse
jog". Setting units are
affected by o1-03.
6.00Hz Yes Q Q Q Q Q 292H
Jog
Reference
Parameter
Number
Name
Description
Setting
Range
Factory
Setting
Change
during
Operation
Control Methods
MODBUS
Register
Display
V/f
V/f
with
PG
Open
Loop
Vector
1
Flux
Vector
Open
Loop
Vector
2
