User Parameter Tables
5-33
Field Control: d6
User parameters for the field weakening command are shown in the following table.
Parameter
Number
Name
Description
Setting
Range
Factory
Setting
Change
during
Operation
Control Methods
MODBUS
Register
Display
V/f
V/f
with
PG
Open
Loop
Vector
1
Flux
Vector
Open
Loop
Vector
2
d6-01
Magnetic
Field
Weakening
Level
Sets the Drive output voltage
when the multi-function input
"field weakening command"
is input (H1-xx = 63). Sets as
a percentage taking the
voltage set in the V/f pattern
as 100%.
0
to
100
80% No A A No No No 2A0H
Field-Weak
Lvl
d6-02
Magnetic
Field
Frequency
Sets the lower limit (in Hz) of
the frequency range where
field weakening control is
valid. The field weakening
command is valid only at
frequencies above this setting
and only when output
frequency is in agreement
with the current output
frequency (speed agree).
0.0
to
400.0
0.0HzH
z
No A A No No No 2A1H
Field-Weak
Freq
d6-03
Magnetic
Field Forcing
Function
Selection
Set the magnetic field forcing
function.
0: Disabled
1: Enabled
0 or 1 0 No No No A A A 2A2H
Field Force
Sel
d6-05
AφR Time
Constant
Sets the A-phase-R time
constant in relation to the
motor secondary circuit time
constant by the amount of
increase.
Note: A-phase-R Time
Constant = (Secondary
Circuit Time Constant)
x (d6-05).
When d6-05 = 0, then
A-phase-R is inactive.
When d6-05 = 0, it
becomes the lower limit
for 200ms internal to the
drive.
0.00
to
10.00
1.00 No No No No No A 2A4H
A PHI R
Filter
d6-06
Magnetic
Field Forcing
Limit
Sets the upper limit of the
excitation current command
during magnetic field forcing.
A setting of 100% is equal to
motor no-load current, E2-03.
100
to
400
400% No No No A A A 2A5H
Field Force
Limit
