YASKAWA G7 Series User Manual

User Parameter Tables
5-49
F6-04
Trace
Sampling
from
Communication
Option Board
Sets the sample trace for the
CP-916 option board.
0
to
60000
0NoAAAAA3A5H
Trace
Sample Tim
F6-05
Current
Monitor Unit
Display
Selection
Selects the current monitor
scaling when using a
communication option board.
0: Displayed in Amps
1: 100% / 8192
(12 bit binary number
with 8192=100% Drive’s
rated current)
0 or 1 0 No A A A A A 3A6H
Current Unit
Sel
F6-06
Torque
Reference/
torque Limit
Selection
from
Communication
Option
Selects torque reference/
limit when using
communications option board.
0: Disabled - Torque
reference/limit from
option board disabled
1: Enabled - Torque
reference/limit from
option board enabled.
0 or 1 0 No No No No A A 3A7H
Torq Ref/Lmt
Sel
Parameter
Number
Name
Description
Setting
Range
Factory
Setting
Change
during
Operation
Control Methods
MODBUS
Register
Display
V/f
V/f
with
PG
Open
Loop
Vector
1
Flux
Vector
Open
Loop
Vector
2
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

YASKAWA G7 Series Specifications

General

Series	G7
Frequency	50/60 Hz
Output Voltage	Matches Input Voltage
Control Method	V/f Control
Overload Capacity	150% for 60 seconds
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit
Communication	RS-485, Modbus, DeviceNet, Profibus, Ethernet
Safety	Safe Torque Off (STO)
Operating Temperature	-10°C to 50°C
Humidity	5% to 95% (non-condensing)
Cooling Method	Fan Cooled
Enclosure Rating	IP20
Storage Temperature	-20°C to 65°C
