YASKAWA G7 Series User Manual

User Parameter Tables
5-51
* Number in parenthesis indicates the initial value when using a 3-wire sequence.
Multi-function Contact Input Functions
H1-07
Multi-
Function
Digital Input
Terminal S9
Function
Selection
Multi-Function Relay Input 7 0 to 79 5 No A A A A A 406H
Terminal S9 Sel
H1-08
Multi-
Function
Digital Input
Terminal S10
Function
Selection
Multi-Function Relay Input 8 0 to 79 32 No A A A A A 407H
Terminal S10 Sel
H1-09
Multi-
Function
Digital Input
Terminal S11
Function
Selection
Multi-Function Relay Input 9 0 to 79 7 No A A A A A 408H
Terminal S11 Sel
H1-10
Multi-
Function
Digital Input
Terminal S12
Function
Selection
Multi-Function Relay Input 10 0 to 79 15 No A A A A A 409H
Terminal S12 Sel
Setting
Value
Function
Control Methods
V/f
V/f
with
PG
Open
Loop
Vector
1
Flux
Vector
Open
Loop
Vector
2
0 3-wire sequence (Forward/Reverse Run command) Yes Yes Yes Yes Yes
1 Local/Remote selection (ON: Operator, OFF: Parameter setting) Yes Yes Yes Yes Yes
2 Option/Inverter selection (ON: Option Card) Yes Yes Yes Yes Yes
3
Multi-step speed reference 1
When H3-05 is set to 2, this function is combined with the master/auxiliary speed
switch.
Yes Ye s Yes Yes Yes
4 Multi-step speed reference 2 Yes Yes Yes Yes Yes
5 Multi-step speed reference 3 Yes Yes Yes Yes Yes
6 Jog frequency command (higher priority than multi-step speed reference) Yes Yes Yes Yes Yes
7 Accel/decel time 1 Yes Yes Yes Yes Yes
8 External baseblock NO (NO contact: Baseblock at ON) Yes Yes Yes Yes Yes
9 External baseblock NC (NC contact: Baseblock at OFF) Yes Yes Yes Yes Yes
A
Acceleration/deceleration ramp hold (ON: Acceleration/deceleration stopped,
frequency on hold)
Yes Ye s Yes Yes Yes
B OH2 alarm signal input (ON: OH2 will be displayed) Yes Yes Yes Yes Yes
Parameter
Number
Name
Description
Setting
Range
Factory
Setting
Change
during
Operation
Control Methods
MODBUS
Register
Display
V/f
V/f
with
PG
Open
Loop
Vector
1
Flux
Vector
Open
Loop
Vector
2
