YASKAWA G7 Series User Manual

6-118
Table 11 V/f Pattern Default Settings for Drive Capacity 55~300kW for 240V Class (Continued)
Parameter
No.
Name Unit Factory Setting
E1-03 V/f Pattern Selection – 8 9 A B C D E F
E1-04
Max. Output
Frequency
Hz 50.0 50.0 60.0 60.0 90.0 120.0 180.0 60.0
E1-05 Max. Output Voltage V 240.0 240.0 240.0 240.0 240.0 240.0 240.0 240.0
E1-06
Base
Frequency
Hz 50.0 50.0 60.0 60.0 60.0 60.0 60.0 60.0
E1-07
Mid. Output
Frequency A
V 2.5 2.5 3.0 3.0 3.0 3.0 3.0 3.0
E1-08
Mid. Output
Voltage A
V 17.2 23.0 17.2 23.0 13.8 13.8 13.8 13.8
E1-09
Min. Output
Frequency
Hz 1.3 1.3 1.5 1.5 1.5 1.5 1.5 1.5
E1-10
Mid. Output
Vo l t a g e
V 8.0 10.3 8.0 12.6 6.9 6.9 6.9 6.9
E1-11
Mid Output Fre-
quency B
Hz 0 0 0 0 0 0 0 0
E1-12
Mid Output Voltage
B
V0 0 0 0 0 0 0 0
E1-13 Base Voltage V 0 0 0 0 0 0 0 0
For 480V class units, the value is twice that of 240V class units.
