YASKAWA G7 Series - Page 365

Digital Operator Functions
6-147
Comparing Drive Parameters and Digital Operator Parameter Set Values (VERIFY)
To compare Drive parameters and Digital Operator parameter set values, make the settings using the following
method.
Table 6.3 VERIFY Function Procedure
Step
No.
Digital Operator Display Explanation
1 Press the MENU Key. and select advanced programming mode.
2 Press the DATA/ENTER Key, and select the parameter monitor display.
3
Display o3-01 (Copy Function Selection) using the Increment Key and Decrement
Key.
4 Press the DATA/ENTER Key, and select the function setting display.
5 Change the set value to 3 using the Increment Key.
6
Set the changed data using the DATA/ENTER Key. The VERIFY function will
start.
7 If the VERIFY function ends normally, End is displayed on the Digital Operator.
8 The display returns to o3-01 when a key is pressed.
** Main Menu **
-ADV-
Programming
Initialization
-ADV-
A1 - 00=1
Select Language
COPY Function
-ADV-
o3 - 01=0
Copy Funtion Sel
Copy Funtion Sel
-ADV-
o3-01= 0
COPY SELECT
*0*
Copy Funtion Sel
-ADV-
o3-01= 3
*0*
VERIFY
-ADV-
DATA VERIFYING
VERIFY
-ADV-
VERIFY COMPLETE
Copy Funtion Sel
-ADV-
o3 - 01=0
COPY SELECT
*0*
