Options
6-157
Setting Output Items for the DO-02C Digital Output Card
If using DO-02C Digital Output Card, set the output items using F5-01 and F5-02.
Setting Output Items for the DO-08 Digital Output Card
If using DO-08 Digital Output Card, select one of the following three output modes according to the setting in
F5-09.
F5-05
DO-08 Channel
5 Output Selec-
tion
Sets the digital output function
number for channel 5. See the H2
parameter group for possible
selections.
Enabled when digital output card
DO-02 or DO-08 is used.
0 to 37 6 No A A A A A
DO Ch5 Select
F5-06
DO-08 Channel
6 Output Selec-
tion
Sets the digital output function
number for channel 6. See the H2
parameter group for possible
selections.
Enabled when digital output card
DO-02 or DO-08 is used.
0 to 37 37 No A A A A A
DO Ch6 Select
F5-07
DO-08 Channel
7 Output Selec-
tion
Sets the digital output function
number for channel 7. See the H2
parameter group for possible
selections.
Enabled when digital output card
DO-02 or DO-08 is used.
0 to 37 F No A A A A A
DO Ch7 Select
F5-08
DO-08 Channel
8 Output Selec-
tion
Sets the digital output function
number for channel 8. See the H2
parameter group for possible
selections.
Enabled when digital output card
DO-02 or DO-08 is used.
0 to 37 F No A A A A A
DO Ch8 Select
F5-09
DO-08 Output
Mode Selection
Sets the function of the DO-08
digital output option board.
0: 8-channel individual outputs.
1: Binary code output.
2: 8-channel Selected - Output
according to F5-01 to F5-08
settings.
0 to 2 0 NoAAAAA
DO-08 Selec-
tion
Parameter
Number
Name
Description
Setting
Range
Factory
Setting
Change
during
Operation
Control Methods
Display
V/f
V/f
with
PG
Open
Loop
Vector
1
Flux
Vector
Open
Loop
Vector
2
