YASKAWA G7 Series User Manual

6-158
F5-09 Set to 0
F5-09 Set to 1
The following table shows the code outputs.
F5-09 Set to 2
Output depends on the settings in F5-01 to F5-08.
Set Value
Terminal
Number
Output Details
0: 8 separate
outputs
TD5-TD11 Overcurrent (SC, OC, GF)
TD6-TD11 Overvoltage (OV)
TD7-TD11 Drive overload (OL2)
TD8-TD11 Fuse blown (PUF)
TD9-TD11 Overspeed (OS)
TD10-TD11 Drive overheated (OH1) or motor overload (OL1)
TD1-TD2 Zero speed detected
TD3-TD4 Speed agreement
Set Value
Terminal
Number
Output Details
1: Binary code
output
TD5-TD11 bit 0
Encoded output
(Refer to table below)
TD6-TD11 bit 1
TD7-TD11 bit 2
TD8-TD11 bit 3
TD9-TD11 Zero speed detected
TD10-TD11 Speed agreement
TD1-TD2 Operating
TD3-TD4 Minor fault
Bits 3, 2, 1,
and 0
Output Details
Bits 3, 2, 1,
and 0
Output Details
0000 No error 1000 External fault (EFxx)
0001 Overcurrent (SC, OC, GF) 1001 Controller error (CPFxx)
0010 Overvoltage (OV) 1010 Motor overload (OL1)
0011 Drive overload (OL2) 1011 Not used
0100 Drive overheated (OH, OH1) 1100 Power loss (UV1, UV2, or UV3)
0101 Overspeed (OS) 1101 Speed deviation (DEV)
0110 Fuse blown (PUF) 1110 PG open circuit (PGO)
0111
Dynamic braking resistor (RH)
Injection brake transistor error (RR)
1111 Not used
