Application Precautions
The DI-08 will not function if F3-01 is set to 6
Selecting the Digital Reference
The range of the digital references is determined by the combination of the settings of o1-03 and F3-01. The
information monitored in U1-01 (Frequency reference) will also change.
DI-16H2 Reference Ranges
When using the DI-16H2, the following ranges can be set depending on the settings of the parameters.
Term i nal Pin No.
8-bit Binary with Sign 2-digit BCD with Sign
F3-01 = 7 F3-01 = 0 to 5
TC
1
Bit 1 (2
0
)
1
BDC digit 1
(0 to 9)
2
Bit 1 (2
1
)
2
3
Bit 1 (2
2
)
4
4
Bit 1 (2
3
)
8
5
Bit 1 (2
4
)
1
BDC digit 2
(0 to 15)
6
Bit 1 (2
5
)
2
7
Bit 1 (2
6
)
4
8
Bit 1 (2
7
)
8
9 Sign signal
10 SET (read) signal
11 Reference common signal (0 V)
