YASKAWA G7 Series User Manual

Wiring Main Circuit Terminals
2-7
* The wire thickness is set for copper wires at 75°C
G7U2037
R/L1, S/L2, T/L3, , 1 U/T1,
V/T2, W/T3, R1/L11, S1/L21, T1/L31
M10
155 to 198
(17.6 to 22.5)
N/A
3/0
(80)
Power cables,
e.g., 600 V
vinyl power
cables
3
M8
78 to 95
(8.8 to 10.8)
Application
Dependent
M10
155 to 198
(17.6 to 22.5)
1
(38)
r/ 1, / 2
M4
11.4 to 12.3
(1.3 to 1.4)
16
(1.25)
G7U2045
R/L1, S/L2, T/L3, , 1, U/T1, V/T2,
W/T3, R1/L11, S1/L21, T1/L31
M10
155 to 198
(17.6 to 22.5)
1/0 × 2P
(50 × 2P)
3
M8
78 to 95
(8.8 to 10.8)
Application
Dependent
M10
155 to 198
(17.6 to 22.5)
1/0
(50)
r/ 1, / 2
M4
11.4 to 12.3
(1.3 to 1.4)
16
(1.25)
G7U2055
, 1
M12
276 to 345
(31.4 to 39.2)
3/0 × 2P
(80 × 2P)
R/L1, S/L2, T/L3, U/T1, V/T2, W/T3,
R1/L11, S1/L21, T1/L31
M10
155 to 198
(17.6 to 22.5)
3/0 × 2P
(80 × 2P)
3
M8
78 to 95
(8.8 to 10.8)
Application
Dependent
M12
155 to 198
(17.6 to 22.5)
2/0
(80)
r/ 1, / 2
M4
11.4 to 12.3
(1.3 to 1.4)
16
(1.25)
G7U2075
R/L1, S/L2, T/L3, , 1
M12
276 to 345
(31.4 to 39.2)
250 × 2P
(150 × 2P)
U/T1, V/T2, W/T3, R1/L11, S1/L21,
T1/L31
M12
276 to 345
(31.4 to 39.2)
4/0 × 2P
(100 × 2P)
3
M8
78 to 95
(8.8 to 10.8)
Application
Dependent
M12
276 to 345
(31.4 to 39.2)
2/0 × 2P
(60 × 2P)
r/ 1, / 2
M4
11.4 to 12.3
(1.3 to 1.4)
16
(1.25)
G7U2090
R/L1, S/L2, T/L3, , 1
M12
276 to 345
(31.4 to 39.2)
350 × 2P, or
1/0 × 4P
(200 × 2P, or
50 × 4P)
U/T1, V/T2, W/T3, R1/L11, S1/L21,
T1/L31
M12
276 to 345
(31.4 to 39.2)
300 × 2P, or
1/0 × 4P
(150 × 2P, or
50 × 4P)
3
M8
78 to 95
(8.8 to 10.8)
Application
Dependent
M12
276 to 345
(31.4 to 39.2)
300 × 2P
(150 × 2P)
r/ 1, / 2
M4
11.4 to 12.3
(1.3 to 1.4)
16
(1.25)
G7U2110
R/L1, S/L2, T/L3, , 1
M12
276 to 345
(31.4 to 39.2)
350 × 2P, or
1/0 × 4P
(200 × 2P, or
50 × 4P)
U/T1, V/T2, W/T3, R1/L11, S1/L21, T1/
L31
M12
276 to 345
(31.4 to 39.2)
300 × 2P, or
1/0 × 4P
(150 × 2P, or
50 × 4P)
3
M8
78 to 95
(8.8 to 10.8)
N/A
Application
Dependent
M12
276 to 345
(31.4 to 39.2)
N/A
300 × 2P
(150 × 2P)
r/ 1, / 2
M4
11.4 to 12.3
(1.3 to 1.4)
N/A
16
(1.25)
Drive Model
CIMR-
Terminal Symbol
Terminal
Screws
Clamping
Torque
lb•in(N•m)
Terminal
Block
Acceptable
Wire Range
AWG(mm
2
)
Recommended
Wire Size
AWG
(mm
2
)
Wire Type
