YASKAWA G7 Series User Manual

Wiring Main Circuit Terminals
2-11
Table 2.3 Closed-loop Connector Sizes (JIS C2805) (200-240 V Class and 380-480 V Class)
Wire Size * Terminal Screw
Ring Tongue (R-Type) Closed-Loop Connectors (Lugs)
JST Corporation Part Numbers **
AWG mm
2
20 0.5
M3.5 1.25 - 3.7
M4 1.25 - 4
18 0.75
M3.5 1.25 - 3.7
M4 1.25 - 4
16 1.25
M3.5 1.25 - 3.7
M4 1.25 - 4
14 2
M3.5 2 - 3.7
M4 2 - 4
M5 2 - 5
M6 2 - 6
M8 2 - 8
12 / 10 3.5 / 5.5
M4 5.5 - 4
M5 5.5 - 5
M6 5.5 - 6
M8 5.5 - 8
88
M5 8 - 5
M6 8 - 6
M8 8 - 8
614
M5 14 - 5
M6 14 - 6
M8 14 - 8
422
M5 22 - 5
M6 22 - 6
M8 22 - 8
3 / 2 30 / 38
M6 38 - 6
M8 38 - 8
1 / 1/0 50 / 60
M8 60 - 8
M10 60 - 10
2/0 70
M8 70 - 8
M10 70 - 10
3/0 80
M10 80 - 10
M16 80 - 16
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

YASKAWA G7 Series Specifications

General

Series	G7
Frequency	50/60 Hz
Output Voltage	Matches Input Voltage
Control Method	V/f Control
Overload Capacity	150% for 60 seconds
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit
Communication	RS-485, Modbus, DeviceNet, Profibus, Ethernet
Safety	Safe Torque Off (STO)
Operating Temperature	-10°C to 50°C
Humidity	5% to 95% (non-condensing)
Cooling Method	Fan Cooled
Enclosure Rating	IP20
Storage Temperature	-20°C to 65°C
