10-24
* 1. Not initialized. (Japanese standard specifications: A1-01 = 1, A1-02 = 2)
* 2. The factory setting will change if the control method is changed. The factory settings given above are for V/f without PG control.
* 3. Factory setting depends on the control method (A1-02).
* 4. For V/f with PG control: 1.0
* 5. For Drives with a capacity of 55 kW or more: 2.00
* 6. Setting range and initial setting depend on Drive capacity.
* 7. Setting for 200-240 V class Drives. For 380-480 V class Drives, double the value.
* 8. Factory setting in the parentheses is for 3-wire sequence.
* 9. The contents is ignored if the setting is 0.0.
* 10.E1-13 will have the same value as E1-05 after autotuning.
* 11.If the set value is 0, acceleration will be to the speeds for the acceleration times (C1-01 to C1-08)
* 12.The setting range is 10% to 200% of the Drive rated output. (The value given is for a 200-240 V Class Drive for 0.4 kW.)
L8-18 Soft CLA selection 1 o2-01
LOCAL/REMOTE key enable/dis-
able
1
n1-01
Hunting-prevention function selec-
tion
1 o2-02
STOP key during control circuit
terminal operation
1
n1-02 Hunting-prevention gain 1.00 o2-03 User parameter initial value 0
n2-01
Speed feedback detection control
(AFR) gain
1.00 o2-04 kVA selection
0
*6
n2-02
Speed feedback detection control
(AFR) time constant
50 o2-05
Frequency reference setting
method selection
0
n2-03
Speed feedback detection control
(AFR) time constant 2
750 o2-06
Operation selection when digital
operator is disconnected
0
n3-01
High-slip braking deceleration fre-
quency width
5 o2-07 Cumulative operation time setting 0
n3-02 High-slip braking current limit 150 o2-08
Cumulative operation time selec-
tion
0
n3-03 High-slip braking stop dwell time 1.0 o2-10 Fan operation time setting 0
n3-04 High-slip braking OL time 40 o2-12
Fault trace/fault history clear func-
tion
0
n4-07 Integral time of speed estimator 0.100 o3-01 Copy function selection 0
n4-08
Proportional gain of speed estima-
tor
15 o3-02 Read permitted selection 0
n4-17 Torque adjustment gain 0.8 T1-00 Motor 1/2 selection 1
n4-18 Feeder resistance adjustment gain 1.00 T1-01 Autotuning mode selection 0
n5-01 Feed forward control selection 0 T1-02 Motor output power 0.40
n5-02 Motor acceleration time 0.178 T1-03 Motor rated voltage
200.0
*7
n5-03
Feed forward proportional gain
1.0 T1-04 Motor rated current
1.90
*6
o1-01 Monitor selection 6 T1-05 Motor base frequency 60.00
o1-02 Monitor selection after power up 1 T1-06 Number of motor poles 4
o1-03
Frequency units of reference set-
ting and monitor
0 T1-07 Motor base speed 1750
o1-04
Setting unit for frequency parame-
ters related to V/f characteristics
0 T1-08
PG pulses per revolution for teach-
ing
600
o1-05 LCD brightness adjustment 3
Table 10.7 User Parameters (Continued)
No. Name
Factory
Setting
Setting No. Name
Factory
Setting
Setting
