Fieldbus PCI-Card
Hardware installation
Fig. 3 Remove installation frame
2. Remove the cover and the retaining bracket for the PCI-card. Loosen the indicated screws, see
Fig. 4 Cover.
Fig. 4 Cover
3. Insert the PCI-card in an available slot. See Fig. 5 PCI-card in slot.
Reg.No. ME00107EN-02 Page 13
