Fieldbus PCI-Card
Hardware installation
Fig. 5 PCI-card in slot
4. Install the installation frame in the CPU-rack and fasten it using the 4 screws. See Fig. 6 Installed
frame.
Fig. 6 Installed frame
A. Screw
Page 14 Reg.No. ME00107EN-02
