YASKAWA SGM H Series - Page 56

2.5 Selecting Cables
2-19
2
Name Length Type Specifications
Refer-
ence
c
Encoder
Cable
Cable with connec-
tors at both ends
3 m
(9.84 ft)
JZSP-CMP00-03
5.4.1
5 m
(16.4 ft)
JZSP-CMP00-05
10 m
(32.8 ft)
JZSP-CMP00-10
15 m
(49.2 ft)
JZSP-CMP00-15
20 m
(65.6 ft)
JZSP-CMP00-20
Cable with loose
wire at encoder
end
3 m
(9.84 ft)
JZSP-CMP03-03
5.4.3
5 m
(16.4 ft)
JZSP-CMP03-05
10 m
(32.8 ft)
JZSP-CMP03-10
15 m
(49.2 ft)
JZSP-CMP03-15
20 m
(65.6 ft)
JZSP-CMP03-20
Flexible type
cable with connec-
tors at both ends
3 m
(9.84 ft)
JZSP-CMP10-03
5.4.5
5 m
(16.4 ft)
JZSP-CMP10-05
10 m
(32.8 ft)
JZSP-CMP10-10
15 m
(49.2 ft)
JZSP-CMP10-15
20 m
(65.6 ft)
JZSP-CMP10-20
Flexible type
cable with loose
wire at encoder
end
3 m
(9.84 ft)
JZSP-CMP13-03
5 m
(16.4 ft)
JZSP-CMP13-05
10 m
(32.8 ft)
JZSP-CMP13-10
15 m
(49.2 ft)
JZSP-CMP13-15
20 m
(65.6 ft)
JZSP-CMP13-20
CN2
SERVOPACK
end
Encoder
end
Encoder
end
SERVOPACK
end
SERVOPACK
end
Encoder
end
SERVOPACK
end
Encoder
end
