YASKAWA XTRAWARE - V3.0 - Troubleshooting

Serial Interface Protocol
6.3. Troubleshooting
Table 17: Serial Interface Protocol Troubleshooting
roblem ossibleause
Solution
Unable to establish
communication with
XtraDrive
Communication cable does
not match XtraDrive
requirements.
See cable scheme in XtraDrive
User Manual, (See section in
Appendix E10.)
Communication setting is
different than XtraDrive
requirements.
See section
4.1.1,
Communication Settings.
XtraDrive axis address is
different than the one
referred to by the master.
Match axis address (a –
second byte) to XtraDrive axis
address (Pn000.2).
XtraWare (or any other
program that
communicates with the
COM port) is online.
Close all programs that
communicate with COM port.
The response message
format or value is
different than
expected.
The response message
which accepts Data
Request Commands
response does not match
the master command.
To accept a specific response
message, write a loop with
POLLING command
(Command Operational Code
0x00) until the appropriate
response message is
accepted.
After a variable has been
watched in the XtraWare
variable watch-window
(even if XtraWare is no
longer open), message
response type is changed
to 3 (m=3) and the
message format holds the
variable value as well.
To delete a variable from the
watch list, set XtraWare to
Online mode. Delete the
desired variable(s) and return
to Offline mode. If XtraWare is
closed, rerun the program and
go Online and then Offline.
No checksum value
accepted on the
response message.
Pn2C6 setting is different
than 0x0001.
Set Pn2C6=0001 and reset
XtraDrive.
XtraWare User Manual 191
