YASKAWA XTRAWARE - V3.0 - Table 25: Output Signal Selections

Parameter Reference
8.7. Table 25: Output Signal Selections
Table 25: Output Signal Selections
Parameter Digit
Place
Name Setting Description Default
Setting
0 Disabled
1 Outputs from the SO1
(CN1-25, 26) output
terminal
2 Outputs from the SO2
(CN1-27, 28) output
terminal
0 /COIN Signal
Mapping
3 Outputs from the SO3
(CN1-29, 30) output
terminal
0:Disabled
1 /V-CMP Signal
Mapping
0 to 3 Same as above 0:Disabled
2 /TGON Signal
Mapping
0 to 3 Same as above 0:Disabled
Pn50E
3 /S-RDY Signal
Mapping
0 to 3 Same as above 0:Disabled
0 /CLT Signal
Mapping
0 to 3 Same as above
1 /VLT Signal
Mapping
0 to 3 Same as above
2 /BK Signal
Mapping
0 to 3 Same as above
Pn50F
3 /WARN Signal
Mapping
0 to 3 Same as above
0 /NEAR Signal
Mapping
0 to 3 Same as above
1 Reserved 0 to 3 Same as above
0: Not used
2 Not used 0 - 0
Pn510
3 Not used 0 - 0
Note:
Output states can not be monitored in watch window/variables
unless they are assigned as programmable outputs in a
program.
230 XtraWare User Manual
