YASKAWA XTRAWARE - V3.0 - Table 23: Home Switches; Table 24: Extended Input Signal Selection

Parameter Reference
8.5. Table 23: Home Switches
Table 23: Home Switches
Parameter Digit Place Name Setting Description Default
Setting
0 Home switch
input
Same as Pn50A.1 8
1 Reserved - - 0
2 Reserved - - 0
Pn2C7
3 Reserved 0
Note:
When working in YASKAWA Option Board Mode, all input and
output assignments are available. When working in modes C
and D, consult Table 27: Input and Output Availability per
Mode for a list of input and output signals that can be
assigned.
8.6. Table 24: Extended Input Signal
Selection
The inputs listed in the table below are used in the user program.
Table 24: Extended Input Signal Selection
Parameter Digit Place Name Setting Description Default
Setting
0 Emergency input 0 Same as Pn50A.1 8: ON
1 New Move
Enable
0-F Same as Pn50A.1 7
2 Reserved - - 0
Pn2D1
3 Reserved - - 0
Note:
When working in YASKAWA Option Board Mode, all input and
output assignments are available. When working in modes C
and D, consult Table 27: Input and Output Availability per
Mode for a list of input and output signals that can be
assigned.
XtraWare User Manual 229
