Operating the XtraDrive Using XtraWare
Note:
After downloading a profile, it is saved in the XtraDrive. Unlike
parameters and programs which can be uploaded from the XtraDrive
to XtraWare, ECAM tables cannot be uploaded. Thus, it is important
that profiles are saved on a disk for backup purposes.
4.9.5.8. Completing a Profile
¾ To complete your profile definition:
1. Once you have completed the profile, click Finish.
2. The Electronic Cam window is closed.
4.9.6. Loading a Profile
You can load and use profiles that have previously been saved. It does not
matter if the profile was originally written for a different project.
¾ To load a profile:
1. Select Electronic CAM from the Tool menu, or click Electronic Cam
on the toolbar.
The Electronic CAM window is displayed.
2. Enter a number that you will use to identify the profile in the Profile
Number field.
3. Click Add Profile.
The profile is added to the Profile List.
4. Click on the Position Setting tab.
5. Click Open in the Cam Profile File area.
The Open Cam Profile dialog box is displayed.
6. Select the file to open, and click Open.
The segments of the opened profile are listed in the Position Setting
tab.
4.9.7. Editing a Profile
4.9.7.1. Inserting Additional Profile Segments
¾ To insert a segment between existing segments in a profile:
1. Click any field in the row of the segment before which the new segment
should be inserted.
2. Click Insert.
A new line is inserted. Enter the required data to define the new
segment.
XtraWare User Manual 57
