Page #122 background imageLoading...
Page #122 background image
The drive uses the delay time set in parameter L8-40 and a hysteresis of 12% when switching the carrier frequency back to
the set value.
n
L8-40: Carrier Frequency Reduction Off-Delay Time
Sets a hold time before returning to the original carrier frequency setting after the carrier frequency has been temporarily
derated as determined by L8-38. The carrier frequency reduction function is disabled when this value is 0.00 s.
No. Name Setting Range Default
L8-40 Carrier Frequency Reduction Off-Delay Time 0.00 to 2.00 s 0.50 s
n
L8-41: High Current Alarm Selection
Triggers a high current alarm (HCA) when the output current exceeds 150% of the drive rated current.
No. Name Setting Range Default
L8-41 High Current Alarm Selection 0, 1 0
Setting 0: Disabled
No alarm is detected.
Setting 1: Enabled
An alarm is triggered when the output current exceeds 150% of the drive rated current. A digital output set for an alarm
(H2-oo = 10) will close.
n
L8-55: Internal Braking Transistor Protection
Enables and disables protection for the internal braking transistor.
No. Name Setting Range Default
L8-55 Internal Braking Transistor Protection 0, 1 1
Setting 0: Disabled
Disable braking transistor protection when not using the internal braking transistor, including the following instances:
When using a regen converter such as DC5.
When using a regen unit such as RC5.
When using external braking transistor options like CDBR units.
When using the drive in common DC bus applications and the internal braking unit is not installed.
Enabling L8-55 under such conditions can incorrectly trigger a braking transistor fault (rr).
Setting 1: Enabled
Enable L8-55 when connecting a braking resistor or a braking resistor unit to the drive built-in braking transistor.
Models 5A0003 to 5A0052 come with a built-in braking transistor.
n
L8-97: Carrier Frequency Reduction Rate during oH Pre-Alarm
Derates the carrier frequency to the level set to L8-39 during oH pre-alarm.
No. Name Setting Range Default
L8-97 Carrier Frequency Reduction Rate during oH Pre-Alarm 0, 1 0
Setting 0: Disabled
Setting 1: Enabled
1.8 L: Protection Functions
122
YASKAWA SIEP YAIZ1U 03B YASKAWA AC Drive – Z1000 Programming Manual
