Binary Output Objects

Table B.9 Binary Output Objects

Object ID Object Name

Modbus

Address

Active Text Inactive Text PV Access

BO1 MF Output M1-M2 0009H:bit 0 ON OFF C

BO2 MF Output M3-M4 0009H:bit 1 ON OFF C

BO3 MF Output MA-MC 0009H:bit 2 ON OFF C

BO4 Ref Sel: PI Setpoint 000FH:bit 1 ON OFF C

BO5 Ref Sel: Term S5 IN 000FH:bit 12 ON OFF C

BO6 Ref Sel: Term S6 IN 000FH:bit 13 ON OFF C

BO7 Refl Sel: Term S7 IN 000FH:bit 14 ON OFF C

Binary Value Objects

Table B.10 Binary Value Objects

Object ID Object Name

Modbus

Address

Active Text Inactive Text PV Access

BV1 RUN FWD 0001H:bit 0 RUN OFF C

BV2 RUN REV 0001H:bit 1 REV OFF C

BV3 EXT FAULT 0001H:bit 2 FAULT OFF C

BV4 FAULT RESET 0001H:bit 3 RESET OFF C

BV5 COM NET 0001H:bit 4 COM LOCAL C

BV6 COM CNTRL 0001H:bit 5 COM LOCAL C

BV7 MF Input 3 Cmd 0001H:bit 6 ON OFF C

BV8 MF Input 4 Cmd 0001H:bit 7 ON OFF C

BV9 MF Input 5 Cmd 0001H:bit 8 ON OFF C

BV10 MF Input 6 Cmd 0001H:bit 9 ON OFF C

BV11 MF Input 7 Cmd 0001H:bit 10 ON OFF C

BV12 Set Fault Contact Cmd 0009H:bit 6 ENABLE OFF C

BV13 RUN-STOP 0020H:bit 0 RUN OFF R

BV14 REV-FWD 0020H:bit 1 REV FWD R

BV15 READY 0020H:bit 2 READY OFF R

BV16 FAULT 0020H:bit 3 FAULTED OFF R

BV17 Data Set Error 0020H:bit 4 ERROR OFF R

BV18 Overcurrent – Ground Fault 0021H:bit 0 OC-GF OFF R

BV19 Main Circuit Overvoltage 0021H:bit 1 OV OFF R

BV20 Drive Overload 0021H:bit 2 OL2 OFF R

BV21 Drive Overheat 0021H:bit 3 OH1-OH2 OFF R

BV22 Fuse Blown 0021H:bit 5 PUF OFF R

BV23 PI Feedback Loss 0021H:bit 6 FBL OFF R

BV24 External Fault 0021H:bit 7 EF0-EF OFF R

BV25 Hardware Error 0021H:bit 8 CPF OFF R

BV26 Mtr Ovrld-OvrTorque 0021H:bit 9 OL1-OL3 OFF R

BV27 Overspeed 0021H:bit 10 OS-DEV OFF R

BV28 Main CKT Undervoltage 0021H:bit 11 UV OFF R

BV29 MCU, Cntl Pwr Sy Err 0021H:bit 12 UV1-2-3 OFF R

BV30 Output Phase Loss 0021H:bit 13 LF OFF R

BV31 Communication Error 0021H:bit 14 CE OFF R

BV32 Operator Disconnect 0021H:bit 15 OPR OFF R

BV33 Operating 002CH:bit 0 OPERATING OFF R

BV34 Aero Speed 002CH:bit 1 ON OFF R

B.7 BACnet Objects Supported

YASKAWA SIEP YAIZ1U 03B YASKAWA AC Drive – Z1000 Programming Manual

259

BACnet

Communications
