YASKAWA Z1000 CIMR-ZU*A Series User Manual

H3 Multi-Function Analog Input Settings
H3-oo
Setting
Function LCD Display Description Page
4 Output voltage bias Voltage Bias 10 V = E1-05 (motor rated voltage) 95
5 Accel/decel time gain Acc/Dec Change 10 V = 100% 95
6
DC Injection Braking
current
DC Brake Current
10 V = Drive rated current
95
7
Overtorque/undertorque
detection level
Torque Det Level
10 V = Drive rated current (V/f)
10 V = Motor rated torque (OLV/PM)
96
8
Stall Prevention level
during run
Stall Prev Level
10 V = Drive rated current
96
9
Output frequency lower
limit level
Ref Lower Limit
10 V = E1-04 (maximum output frequency)
96
B PI feedback PI Feedback1 10 V = 100% 96
C PI setpoint PI Set Point 10 V = 100% 96
D Frequency bias Freq Ref Bias 2 10 V = E1-04 (maximum output frequency) 96
E
Motor temperature (PTC
input)
Motor PTC
10 V = 100%
96
F Through mode Not Used Set this value when using the terminal in the pass-through mode. 96
16 Differential PI feedback PI Feedback 2 10 V = 100% 96
25 Secondary PI Setpoint PI2 Setpoint 10 V = S3-02 (maximum output frequency) 96
26 Secondary PI Feedback PI2 Feedback 10 V = S3-02 (maximum output frequency) 96
u
H4: Analog Outputs
No.
(Addr.
Hex)
Name LCD Display Description Values Page
H4-01
(41D)
Multi-Function Analog
Output Terminal FM
Monitor Selection
Term FM FuncSel
Selects the data to be output through multi-function analog
output terminal FM.
Set the desired monitor parameter to the digits available in
Uo-oo.
For example, enter “103” for U1-03.
Default: 102
Range: 000 to
655
96
H4-02
(41E)
Multi-Function Analog
Output Terminal FM
Gain
Terminal FM Gain
Sets the signal level at terminal FM that is equal to 100% of the
selected monitor value.
Default: 100.0%
Min.: -999.9
Max.: 999.9
97
H4-03
(41F)
Multi-Function Analog
Output Terminal FM
Bias
Terminal FM Bias
Sets the signal level at terminal FM that is equal to 0% of the
selected monitor value.
Default: 0.0%
Min.: -999.9
Max.: 999.9
97
H4-04
(420)
Multi-Function Analog
Output Terminal AM
Monitor Selection
Terminal AM Sel
Selects the data to be output through multi-function analog
output terminal AM.
Set the desired monitor parameter to the digits available in
Uo-oo.
For example, enter “103” for U1-03.
Default: 103
Range: 000 to
655
96
H4-05
(421)
Multi-Function Analog
Output Terminal AM
Gain
Terminal AM Gain
Sets the signal level at terminal AM that is equal to 100% of
the selected monitor value.
Default: 50.0%
Min.: -999.9
Max.: 999.9
97
H4-06
(422)
Multi-Function Analog
Output Terminal AM
Bias
Terminal AM Bias
Sets the signal level at terminal AM that is equal to 0% of the
selected monitor value.
Default: 0.0%
Min.: -999.9
Max.: 999.9
97
H4-07
(423)
Multi-Function Analog
Output Terminal FM
Signal Level Selection
Level Select1
0: 0 to 10 Vdc
1: -10 to 10 Vdc
2: 4-20 mA
0: 0 to 10 V
1: -10 V to 10 V
2: 4 to 20 mA
Default: 0
Range: 0 to 2
98
H4-08
(424)
Multi-Function Analog
Output Terminal AM
Signal Level Selection
AO Level Select2
0: 0 to 10 Vdc
1: -10 to 10 Vdc
2: 4 to 20 mA
0: 0 to 10 V
1: -10 V to 10 V
2: 4 to 20 mA
Default: 0
Range: 0 to 2
98
A.9 H Parameters: Multi-Function Terminals
YASKAWA SIEP YAIZ1U 03B YASKAWA AC Drive – Z1000 Programming Manual
211
A
Parameter List

YASKAWA Z1000 CIMR-ZU*A Series Specifications

General

Series	Z1000 CIMR-ZU*A Series
Category	Controller
Voltage Classes	200V, 400V
Enclosure	NEMA 1, NEMA 12
Frequency Range	0.01 to 400 Hz
Cooling Method	Fan Cooled
Operating Temperature	-10°C to 50°C
Application	HVAC
Control Method	V/f Control
Input Voltage	200-240V, 380-480V
Frequency Range (Input)	50/60 Hz
Power Rating	0.4kW to 630kW
Protection Features	Overcurrent, Overvoltage, Undervoltage
Communication Options	Modbus
Storage Temperature	-20°C to 60°C
Humidity	5% to 95% (non-condensing)
Enclosure Rating	IP20
Output Voltage	0-100% of input voltage
