2.5 Drive Cooling Fans

NOTICE: Follow cooling fan replacement instructions. The cooling fan cannot operate properly when installed incorrectly and could seriously

damage the drive. To ensure maximum useful product life, replace all cooling fans when performing maintenance.

Contact a Yaskawa representative or the nearest Yaskawa sales office to order replacement cooling fans as required.

For drives with multiple cooling fans, replace all the fans when performing maintenance to ensure maximum product

performance life.

Number of Cooling Fans

Drive Model Cooling Fans Circulation Fans Control Board Cooling Fans Page

Three-Phase 600 V Class

5A0003 – – – –

5A0004 – – – –

5A0006 1 – –

171

5A0009 1 – –

5A0011 2 – –

5A0017 2 – –

5A0022 2 – –

5A0027 2 – –

5A0032 2 – –

5A0041 2 – –

172

5A0052 2 – –

5A0062 2 – –

174

5A0077 2 – –

5A0099 2 – –

5A0125 2 – –

5A0145 2 – –

5A0192 3 – –

5A0242 3 1 –

2.5 Drive Cooling Fans

YASKAWA SIEP YAIZ1U 03B YASKAWA AC Drive – Z1000 Programming Manual

169

Periodic Inspection &

Maintenance
