No.
(Addr.
Hex)
Name LCD Display Description Values Page
o1-15
(3107)
Frequency Reference
and Frequency Related
Monitor Custom Units 3
Fref Cust Unit 3
Sets the customer-specified unit display for the frequency
reference parameters and frequency related monitors when
o1-03 = 3 and o1-09 = 15 as custom units
Default: 41
Range: 30 to 7A
130
o1-16
(3108)
F1 Key Function
Selection
F1 Key Func Sel
0: Standard
1: Mon
2: DRV/BYP
3: RUN BYP
4: RLY
Selects the function of the F1 key and the LCD display text
above the F1 key.
0: Standard
1: Monitor
2: Drive/Bypass (DRV/BYP)
3: Bypass Run Command (RUN BYP)
4: Toggle Relay Output (RLY)
Default: 0
Range: 0 to 4
130
o1-17
(3109)
F2 Key Function
Selection
F2 Key Func Sel
0: Standard
1: Mon
2: DRV/BYP
3: RUN BYP
4: RLY
Selects the function of the F2 key and the LCD display text
above the F2 key.
0: Standard
1: Monitor
2: Drive/Bypass (DRV/BYP)
3: Bypass Run Command (RUN BYP)
4: Toggle Relay Output (RLY)
Default: 0
Range: 0 to 4
130
o1-18
(310A)
User Defined Parameter
Upper
Userdefined par1
Allows the user to set values that can be used as reference
information.
Default: 0
Range: 0 to 999
130
o1-19
(310B)
User Defined Parameter
Lower
Userdefined par2
Allows the user to set values that can be used as reference
information.
Default: 0
Range: 0 to 999
130
<1> Default setting is dependent on parameter o1-03, HOA Keypad Display Selection.
u
o2: HOA Keypad Functions
No.
(Addr.
Hex)
Name LCD Display Description Values Page
o2-02
(506)
OFF Key Function
Selection
Oper STOP Key
0: Disabled
1: Enabled
0: Disabled. OFF key is disabled in REMOTE operation.
1: Enabled. OFF key is always enabled.
Default: 1
Range: 0, 1
131
o2-03
(507)
User Parameter Default
Value
User Default Sel
0: No Change
1: Save User Init
2: Clear User Init
0: No change.
1: Set defaults. Saves parameter settings as default values for a
User Initialization.
2: Clear all. Clears the default settings that have been saved for
a User Initialization.
Default: 0
Range: 0 to 2
131
o2-04
(508)
Drive Model Selection Inverter Model #
Enter the drive model. Setting required only if installing a new
control board.
Default:
Determined by
drive capacity
131
o2-05
(509)
Frequency Reference
Setting Method
Selection
Oper Ref Method
0: Disabled
1: Enabled
0: ENTER key must be pressed to enter a frequency reference.
1: ENTER key is not required. The frequency reference can be
adjusted using the up and down arrow keys only.
Default: 0
Range: 0, 1
131
o2-06
(50A)
Operation Selection
when HOA Keypad is
Disconnected
Oper Discon Det
0: Disabled
1: Enabled
0: The drive continues operating if the HOA keypad is
disconnected.
1: An oPr fault is triggered and the motor coasts to stop.
Default: 1
Range: 0, 1
132
o2-07
(527)
Motor Direction at
Power Up when Using
Operator
For/RevSel@PwrUp
0: Forward
1: Reverse
0: Forward
1: Reverse
This parameter requires assigning drive operation to the HOA
keypad.
Default: 0
Range: 0, 1
132
o2-19
(61F)
Selection of Parameter
Write during Uv
ParameterSet Sel
0: Disabled
1: Enabled
Selects whether parameter settings can be changed during a DC
bus undervoltage condition. Used with 24 V Power Supply (PS-
A10L, PS-A10H).
0: Disabled
1: Enabled
Default: 0
Range: 0, 1
132
A.12 o: Operator-Related Settings
222
YASKAWA SIEP YAIZ1U 03B YASKAWA AC Drive – Z1000 Programming Manual
