YASKAWA Z1000 CIMR-ZU*A Series User Manual

B.2 Communication Specifications
BACnet specifications appear in the following table:
Item Specifications
Interface
MS-TP (Master-Slave/Token-Passing)
RS-485
Communication Parameters
Communication Speeds: 1200, 2400, 4800, 9600, 19200, 38400, 57600, 76800 bps
Data Length: 8-bit (fixed)
Parity: Select Even, Odd, or None
Stop Bit: 1-bit (fixed)
Protocol BACnet MS-TP
Max Number of Drives 127 per MS-TP Network Segment
B.2 Communication Specifications
YASKAWA SIEP YAIZ1U 03B YASKAWA AC Drive – Z1000 Programming Manual
247
B
BACnet Communications

YASKAWA Z1000 CIMR-ZU*A Series Specifications

General

Series	Z1000 CIMR-ZU*A Series
Category	Controller
Voltage Classes	200V, 400V
Enclosure	NEMA 1, NEMA 12
Frequency Range	0.01 to 400 Hz
Cooling Method	Fan Cooled
Operating Temperature	-10°C to 50°C
Application	HVAC
Control Method	V/f Control
Input Voltage	200-240V, 380-480V
Frequency Range (Input)	50/60 Hz
Power Rating	0.4kW to 630kW
Protection Features	Overcurrent, Overvoltage, Undervoltage
Communication Options	Modbus
Storage Temperature	-20°C to 60°C
Humidity	5% to 95% (non-condensing)
Enclosure Rating	IP20
Output Voltage	0-100% of input voltage
