YASKAWA Z1000 CIMR-ZU*A Series User Manual

A.17 V/f Pattern Default Values
The following tables show the V/f pattern setting default values depending on the control mode (A1-02) and the V/f pattern
selection (E1-03 in V/f Control).
Table A.4 E1-03 V/f Pattern Settings for Drive Capacity: 5A0003 to 5A0009
No. Unit V/f Control
E1-03 - 0 1 2 3 4 5 6 7 8 9 A B C D E
F
<1>
E1-04 Hz 50.0 60.0 60.0 72.0 50.0 50.0 60.0 60.0 50.0 50.0 60.0 60.0 90.0 120.0 180.0 60.0
E1-05 V 575.0 575.0 575.0 575.0 575.0 575.0 575.0 575.0 575.0 575.0 575.0 575.0 575.0 575.0 575.0 575.0
E1-06 Hz 50.0 60.0 50.0 60.0 50.0 50.0 60.0 60.0 50.0 50.0 60.0 60.0 60.0 60.0 60.0 60.0
E1-07 Hz 2.5 3.0 3.0 3.0 25.0 25.0 30.0 30.0 2.5 2.5 3.0 3.0 3.0 3.0 3.0 3.0
E1-08 V 43.1 43.1 43.1 43.1 100.6 143.8 100.6 143.8 54.6 69.0 54.6 69.0 43.1 43.1 43.1 43.1
E1-09 Hz 1.3 1.5 1.5 1.5 1.3 1.3 1.5 1.5 1.3 1.3 1.5 1.5 1.5 1.5 1.5 1.5
E1-10 V 25.9 25.9 25.9 25.9 23.0 25.9 23.0 25.9 31.6 37.4 31.6 43.1 25.9 25.9 25.9 25.9
<1> This value determines the default values for E1-04 through E1-10 (E3-04 through E3-10 for motor 2).
Table A.5 E1-03 V/f Pattern Settings for Drive Capacity: 5A0011 to 5A0077
No. Unit V/f Control
E1-03 - 0 1 2 3 4 5 6 7 8 9 A B C D E
F
<1>
E1-04 Hz 50.0 60.0 60.0 72.0 50.0 50.0 60.0 60.0 50.0 50.0 60.0 60.0 90.0 120.0 180.0 60.0
E1-05 V 575.0 575.0 575.0 575.0 575.0 575.0 575.0 575.0 575.0 575.0 575.0 575.0 575.0 575.0 575.0 575.0
E1-06 Hz 50.0 60.0 50.0 60.0 50.0 50.0 60.0 60.0 50.0 50.0 60.0 60.0 60.0 60.0 60.0 60.0
E1-07 Hz 2.5 3.0 3.0 3.0 25.0 25.0 30.0 30.0 2.5 2.5 3.0 3.0 3.0 3.0 3.0 3.0
E1-08 V 40.3 40.3 40.3 40.3 100.6 143.8 100.6 143.8 51.8 67.0 51.8 67.0 40.3 40.3 40.3 40.3
E1-09 Hz 1.3 1.5 1.5 1.5 1.3 1.3 1.5 1.5 1.3 1.3 1.5 1.5 1.5 1.5 1.5 1.5
E1-10 V 20.1 20.1 20.1 20.1 17.3 20.1 17.3 20.1 25.9 31.6 25.9 37.4 20.1 20.1 20.1 20.1
<1> This value determines the default values for E1-04 through E1-10 (E3-04 through E3-10 for motor 2).
Table A.6 E1-03 V/f Pattern Settings for Drive Capacity: 5A0099 to 5A0242
No. Unit V/f Control
E1-03 - 0 1 2 3 4 5 6 7 8 9 A B C D E
F
<1>
E1-04 Hz 50.0 60.0 60.0 72.0 50.0 50.0 60.0 60.0 50.0 50.0 60.0 60.0 90.0 120.0 180.0 60.0
E1-05 V 575.0 575.0 575.0 575.0 575.0 575.0 575.0 575.0 575.0 575.0 575.0 575.0 575.0 575.0 575.0 575.0
E1-06 Hz 50.0 60.0 50.0 60.0 50.0 50.0 60.0 60.0 50.0 50.0 60.0 60.0 60.0 60.0 60.0 60.0
E1-07 Hz 2.5 3.0 3.0 3.0 25.0 25.0 30.0 30.0 2.5 2.5 3.0 3.0 3.0 3.0 3.0 3.0
E1-08 V 34.5 34.5 34.5 34.5 100.6 143.8 100.6 50.0 43.1 57.5 43.1 57.5 34.5 34.5 34.5 34.5
E1-09 Hz 1.3 1.5 1.5 1.5 1.3 1.3 1.5 1.5 1.3 1.3 1.5 1.5 1.5 1.5 1.5 1.5
E1-10 V 17.3 17.3 17.3 17.3 14.4 17.3 14.4 17.3 20.1 25.9 20.1 31.6 17.3 17.3 17.3 17.3
<1> This value determines the default values for E1-04 through E1-10 (E3-04 through E3-10 for motor 2).
A.17 V/f Pattern Default Values
240
YASKAWA SIEP YAIZ1U 03B YASKAWA AC Drive – Z1000 Programming Manual
