YASKAWA Z1000 CIMR-ZU*A Series User Manual

A.18 Defaults by Drive Model
The following tables show parameters and default settings that change with the drive model selection (o2-04).
Table A.7 600 V Class Drives Default Settings by Drive Model
No. Name Unit
– Model – 5A0003 5A0004 5A0006 5A0009 5A0011
o2-04 Drive Model Selection Hex. C3 C4 C5 C7
E2-11 Motor Rated Power
kW
(HP)
1.5
(2)
2.2
(3)
3.7
(5)
5.5
(7.5)
7.5
(10)
b3-04 V/f Gain during Speed Search % 100 100 100 100 100
b3-06 Output Current 1 during Speed Search – 0.5 0.5 0.5 0.5 0.5
b8-04 Energy Saving Coefficient Value – 494.4 415.3 320.2 239.95 199.86
C6-02 Carrier Frequency Selection – 7 7 7 7 7
E2-01 Motor Rated Current A 2.7 3.9 6.1 9 11
E2-02 Motor Rated Slip Hz 2.5 3.0 2.7 1.5 1.3
E2-03 Motor No-Load Current A 0.8 1.2 1.8 2.7 3.3
E2-05 Motor Line-to-Line Resistance Ω 13.72 8.825 4.936 2.601 1.446
E2-10 Motor Iron Loss for Torque Compensation W 53 77 130 193 263
L2-02 Momentary Power Loss Ride-Thru Time s 0.2 0.3 0.5 0.5 0.8
L2-03
Momentary Power Loss Minimum Baseblock
Time
s 0.5 0.5 0.8 0.8 1
L2-04
Momentary Power Loss Voltage Recovery
Time
s 0.5 0.5 0.6 0.7 0.8
L3-24
Motor Acceleration Time for Inertia
Calculations
s 0.166 0.145 0.154 0.168 0.175
L8-02 Overheat Alarm Level °C 110 110 110 110 115
L8-35 Installation Method Selection – 2 2 2 2 2
L8-38 Carrier Frequency Reduction Selection – 2 2 2 2 2
n1-03 Hunting Prevention Time Constant ms 10 10 10 10 10
No. Name Unit Default Settings
– Model – 5A0017 5A0022 5A0027 5A0032
o2-04 Drive Model Selection Hex. CA CC CD CE
E2-11 Motor Rated Power kW (HP)
11
(15)
15
(20)
18.5
(25)
22
(30)
b3-04 V/f Gain during Speed Search % 100 100 100 100
b3-06 Output Current 1 during Speed Search – 0.5 0.5 0.5 0.5
b8-04 Energy Saving Coefficient Value – 172 154 140 129
C6-02 Carrier Frequency Selection – 7 7 7 7
E2-01 Motor Rated Current A 17 22 27 32
E2-02 Motor Rated Slip Hz 1.7 1.6 1.67 1.7
E2-03 Motor No-Load Current A 5.1 6.6 8.1 9.6
E2-05 Motor Line-to-Line Resistance Ω 1.17 0.9 0.66 0.52
E2-10 Motor Iron Loss for Torque Compensation W 385 440 508 586
L2-02 Momentary Power Loss Ride-Thru Time s 1 2 2 2
L2-03 Momentary Power Loss Minimum Baseblock Time s 1 1.2 1.2 1.2
L2-04 Momentary Power Loss Voltage Recovery Time s 0.9 1 1 1
L3-24 Motor Acceleration Time for Inertia Calculations s 0.27 0.24 0.32 0.36
L8-02 Overheat Alarm Level °C 120 120 115 115
L8-35 Installation Method Selection – 2 2 2 2
L8-38 Carrier Frequency Reduction Selection – 2 2 2 2
n1-03 Hunting Prevention Time Constant ms 10 10 10 10
A.18 Defaults by Drive Model
YASKAWA SIEP YAIZ1U 03B YASKAWA AC Drive – Z1000 Programming Manual
241
A
Parameter List

YASKAWA Z1000 CIMR-ZU*A Series Specifications

General

Series	Z1000 CIMR-ZU*A Series
Category	Controller
Voltage Classes	200V, 400V
Enclosure	NEMA 1, NEMA 12
Frequency Range	0.01 to 400 Hz
Cooling Method	Fan Cooled
Operating Temperature	-10°C to 50°C
Application	HVAC
Control Method	V/f Control
Input Voltage	200-240V, 380-480V
Frequency Range (Input)	50/60 Hz
Power Rating	0.4kW to 630kW
Protection Features	Overcurrent, Overvoltage, Undervoltage
Communication Options	Modbus
Storage Temperature	-20°C to 60°C
Humidity	5% to 95% (non-condensing)
Enclosure Rating	IP20
Output Voltage	0-100% of input voltage
