YASKAWA Z1000 CIMR-ZU*A Series User Manual

No. Name Unit Default Settings
– Model – 5A0041 5A0052 5A0062
o2-04 Drive Model Selection Hex. CF D1 D2
E2-11 Motor Rated Power kW (HP)
30
(40)
37
(50)
45
(60)
b3-04 V/f Gain during Speed Search % 80 80 80
b3-06 Output Current 1 during Speed Search – 0.5 0.5 0.5
b8-04 Energy Saving Coefficient Value – 115.57 97.01 90.07
C6-02 Carrier Frequency Selection – 7 7 7
E2-01 Motor Rated Current A 41 52 62
E2-02 Motor Rated Slip Hz 1.8 1.33 1.6
E2-03 Motor No-Load Current A 12.3 15.6 18.8
E2-05 Motor Line-to-Line Resistance Ω 0.438 0.267 0.21
E2-10 Motor Iron Loss for Torque Compensation W 750 925 1125
L2-02 Momentary Power Loss Ride-Thru Time s 2 2 2
L2-03 Momentary Power Loss Minimum Baseblock Time s 1.2 1.2 1.5
L2-04 Momentary Power Loss Voltage Recovery Time s 1.1 1.2 1.3
L3-24 Motor Acceleration Time for Inertia Calculations s 0.323 0.32 0.387
L8-02 Overheat Alarm Level °C 110 110 110
L8-35 Installation Method Selection – 2 2 2
L8-38 Carrier Frequency Reduction Selection – 2 2 2
n1-03 Hunting Prevention Time Constant ms 10 10 10
No. Name Unit Default Settings
– Model – 5A0077 5A0099
o2-04 Drive Model Selection Hex. D3 D4
E2-11 Motor Rated Power kW (HP)
55
(75)
75
(100)
b3-04 V/f Gain during Speed Search % 80 80
b3-06 Output Current 1 during Speed Search – 0.5 0.5
b8-04 Energy Saving Coefficient Value – 80.87 70.07
C6-02 Carrier Frequency Selection – 7 7
E2-01 Motor Rated Current A 77 99
E2-02 Motor Rated Slip Hz 1.46 1.39
E2-03 Motor No-Load Current A 23.1 29.7
E2-05 Motor Line-to-Line Resistance Ω 0.15 0.099
E2-10 Motor Iron Loss for Torque Compensation W 1260 1600
L2-02 Momentary Power Loss Ride-Thru Time s 2 2
L2-03 Momentary Power Loss Minimum Baseblock Time s 1.8 1.8
L2-04 Momentary Power Loss Voltage Recovery Time s 1.5 1.6
L3-24 Motor Acceleration Time for Inertia Calculations s 0.317 0.533
L8-02 Overheat Alarm Level °C 110 110
L8-35 Installation Method Selection – 2 2
L8-38 Carrier Frequency Reduction Selection – 2 2
n1-03 Hunting Prevention Time Constant ms 10 30
A.18 Defaults by Drive Model
242
YASKAWA SIEP YAIZ1U 03B YASKAWA AC Drive – Z1000 Programming Manual

YASKAWA Z1000 CIMR-ZU*A Series Specifications

General

Series	Z1000 CIMR-ZU*A Series
Category	Controller
Voltage Classes	200V, 400V
Enclosure	NEMA 1, NEMA 12
Frequency Range	0.01 to 400 Hz
Cooling Method	Fan Cooled
Operating Temperature	-10°C to 50°C
Application	HVAC
Control Method	V/f Control
Input Voltage	200-240V, 380-480V
Frequency Range (Input)	50/60 Hz
Power Rating	0.4kW to 630kW
Protection Features	Overcurrent, Overvoltage, Undervoltage
Communication Options	Modbus
Storage Temperature	-20°C to 60°C
Humidity	5% to 95% (non-condensing)
Enclosure Rating	IP20
Output Voltage	0-100% of input voltage
