Page #229 background imageLoading...
Page #229 background image
No.
(Addr.
Hex)
Name LCD Display Description Values Page
S5-07
(3235)
HAND Key Function
Selection (HOA
Keypad)
Oper HAND Key
0: Disabled
1: Enabled
Determines whether the HAND key on the HOA keypad will
be enabled for switching between HAND and AUTO.
0: Disabled
1: Enabled
Default: 1
Range: 0, 1
152
u
S6: Z1000 Protection
No.
(Addr.
Hex)
Name LCD Display Description Values Page
S6-01
(3236)
Emergency Override
Speed
E Override Speed
Sets the speed command used in Emergency Override mode when
S6-02 = 0.
Default: 0.00
Hz
Min.: 0.00
Max.: 240.00
153
S6-02
(3237)
Emergency Override
Reference Selection
E OverrideRefSel
0: Use S6-01 Ref
1: Use AUTO Ref
Selects the frequency reference source for the Emergency
Override function (H1-oo= AF or B0).
0: Use S6-01 Reference
1: Use AUTO Reference
Note: The Emergency Override inputs will function even
if the CALL alarm is displayed.
Default: 0
Range: 0, 1
153
S6-03
(3238)
ov2 Detect Time ov2 Detect Time
Sets the detection time of ov2 in 0.1 s increments. Default: 10.0 s
Min.: 0.0
Max.: 1200.0
153
S6-07
(323C)
Output Phase Loss
Detection Level for
Dynamic Audible Noise
Control
Outp Ph Loss Lv1
Sets the output phase loss detection level for Dynamic Audible
Noise Control. Decrease the setting in steps of 10% when output
phase loss is detected erroneously. This setting rarely needs to be
changed.
Default:
100.0%
Min.: 10.0
Max.: 100.0
153
A.13 S: Special Application
YASKAWA SIEP YAIZ1U 03B YASKAWA AC Drive – Z1000 Programming Manual
229
A
Parameter List
