C.5 APOGEE FLN Point Database
This section shows the APOGEE FLN point database for Application 2721.
u
APOGEE FLN Point List Summary
This database is for APOGEE FLN Application 2721 and features 97 logical points: 29 Logical Analog Inputs (LAI), 35
Logical Analog Outputs (LAO), 19 Logical Digital Inputs (LDI) and 14 Logical Digital Outputs (LDO). These points configure,
control or monitor the operation of the drive.
Information to consider when referencing this table:
1. Points not listed are not used in this application.
2. A single value in a column means that the value is the same in English units and in SI units.
3. Point numbers that appear in bold italic type (e.g. 03) can be unbundled at the field panel.
Table C.3 APOGEE FLN Application 2721 Point Number Summary
Point
Numb
er
Point
Type
Point Name
Factory
Default
(SI
Units)
Eng. Units
(SI Units)
Slope
(SI
Units)
Intercept
(SI Units)
On Text Off Text Parameter
1 LAO
CTLR
ADDRESS
31 – 1 0 – – H5-01
2 LAO APPLICATION – – 1 0 – – –
03 LAI FREQ OUTPUT 0 Hz 0.01 0 – – U1-02
04 LAI PCT OUTPUT 0 % 0.01 0 – – –
05 LAI SPEED 0 RPM 1 0 – – –
06 LAI CURRENT 0 A 0.01 0 – – U1-03
07 LAI TORQUE 0 % 0.1 0 – – –
08 LAI POWER 0 kW 0.1 0 – – U1-08
09 LAI DRIVE TEMP 0 ° C/F 1 0 – – U4-08
10 LAI DRIVE KWH 0 kWh 0.1 0 – – U4-10
11 LAI MWH 0 MWh 1 0 – – U4-11
12 LAI RUN TIME 0 h 1 0 – – U4-01
13 LAI DC BUS VOLT 0 V 1 0 – – U1-07
14 LAI AC OUT VOLT 0 V 0.1 0 – – U1-06
15 LAI PAR N9.01 0 A 0.01 0 – – n9-01
16 LAI RUN TIMEX10K 0 10Kh 1 0 – – U4-01
17 LAI FAULT CODE 0 – 1 0 – – U2-01
18 LDI MINOR FLT NO FLT – 1 0 FAULT NO FLT U1-12 (Bit 6)
19 LDI MAJOR FLT NO FLT – 1 0 FAULT NO FLT U1-12 (Bit 7)
20 LAO OVRD TIME 1 h 1 0 – – –
21 LDI FWD.REV FWD – 1 0 REV FWD U1-12 (Bit 2)
22 LDO CMD REV.STOP STOP – 1 0 REV STOP –
23 LDI RUN.STOP STOP – 1 0 RUN STOP U1-12 (Bit 0)
24 LDO CMD RUN.STOP STOP – 1 0 FWD STOP –
25 LDI ZERO SPEED OFF – 1 0 ON OFF U1-12 (Bit 1)
26 LDI SPEED AGREE NO AGR – 1 0 AGREE NO AGR U1-12 (Bit 4)
27 LDI DRIVE READY NOTRDY – 1 0 READY NOTRDY U1-12 (Bit 5)
28 LDI LOC.REM MON REMOTE – 1 0 LOCAL REMOTE –
29 LDO DAY.NGT DAY – 1 0 NGT DAY –
30 LAO CURRENT LMT 0 A 0.01 0 – – E2-01
31 LAO ACCEL TIME 0 s 0.1 0 – – C1-01
32 LAO DECEL TIME 0 s 0.1 0 – – C1-02
33 LDO LOCK PANEL UNLOCK – 1 0 LOCK UNLOCK –
C.5 APOGEE FLN Point Database
YASKAWA SIEP YAIZ1U 03B YASKAWA AC Drive – Z1000 Programming Manual
275
C
APOGEE FLN (P1)
Communications
