YASKAWA Z1000 CIMR-ZU*A Series

Point
Numb
er
Point
Type
Point Name
Factory
Default
(SI
Units)
Eng. Units
(SI Units)
Slope
(SI
Units)
Intercept
(SI Units)
On Text Off Text Parameter
35
<1>
LDO RUN ENABLE STOP – 1 0
ENABL
E
STOP –
36 LAO STALL PRE RN 90 % 1 30 – – L3-06
37 LAO STALL PRE AC 120 % 1 0 – – L3-02
38 LAO FREQ UP LIM 100 % 0.1 0 – – d2-01
39 LAO FREQ LOW LIM 0 % 0.1 0 – – d2-02
40 LDI MULTI OUT 1 OFF – 1 0 ON OFF U1-11 (Bit 0)
41 LDI MULTI OUT 2 OFF – 1 0 ON OFF U1-11 (Bit 1)
42 LDI MULTI OUT 3 OFF – 1 0 ON OFF U1-11 (Bit 2)
43 LDI SAFETY ILOCK OFF – 1 0 ON OFF U1-10 (Bit 2)
44 LDO MF INP 1 OFF – 1 0 ON OFF –
45 LDO MF INP 2 OFF – 1 0 ON OFF –
46 LDO MF INP 3 OFF – 1 0 ON OFF –
47 LDO MF INP 4 OFF – 1 0 ON OFF –
48 LDO MF INP 5 OFF – 1 0 ON OFF –
49 LAO JUMP FREQ 1 0 Hz 0.1 0 – – d3-01
50 LAO JUMP FREQ 2 0 Hz 0.1 0 – – d3-02
51 LAO JUMP FREQ 3 0 Hz 0.1 0 – – d3-03
52 LAO JUMP FREQ BW 0 Hz 0.1 0 – – d3-04
53 LAO
NUM
AUTOSTRT
0 – 1 0 – – L5-01
54 LAO
POWER LOSS
RT
0.1 s 0.1 0 – – L2-02
55 LAO RUN OP MODE 1 – 1 0 – – b1-02
56 LAO REF OP MODE 1 – 1 0 – – b1-01
57 LAO OPER DISP MD 0 – 1 0 – – o1-03
58 LDI MF IN 1 MON OFF – 1 0 ON OFF U1-10 (Bit 2)
59 LDI MF IN 2 MON OFF – 1 0 ON OFF U1-10 (Bit 3)
60 LAO INPUT REF 1 0 Hz 0.01 0 – – –
61 LAO INPUT REF 2 0 Hz 0.01 0 – – d1-02
62 LAI PID FEEDBACK 0 % 0.01 0 – – U5-01
63 LAO PID P GAIN 2 – 0.01 0 – – b5-02
64 LAO PID I TIM 0.5 s 0.1 0 – – b5-03
65 LDO PID MODE SEL DISABLE – 1 0
ENABL
E
DISABLE b5-01
66 LAI LST FLT CODE 0 – 1 0 – – U2-02
67 LAI FREF.FLT 0 Hz 0.01 0 – – U2-03
68 LAI OUT FREQ FLT 0 Hz 0.01 0 – – U2-04
69 LAI OUT CUR.FLT 0 A 0.01 0 – – U2-05
70 LAO
RD PARAM
NUM
1 – 1 0 – – –
71 LAI
RD PARAM
DAT
0 – 1 0 – – –
72 LAO
WR PARAM
NUM
1 – 1 0 – – –
73 LAO
WR PARAM
DAT
0 – 1 0 – – –
74 LDI MF IN 3 MON OFF – 1 0 ON OFF U1-10 (Bit 4)
75 LAI OUT VOLT.FLT 0 V 0.1 0 – – U2-07
76 LAI DC BUS.FLT 0 V 1 0 – – U2-08
77 LAI OUT PWR.FLT 0 kW 0.1 0 – – U2-09
C.5 APOGEE FLN Point Database
276
YASKAWA SIEP YAIZ1U 03B YASKAWA AC Drive – Z1000 Programming Manual
