YASKAWA Z1000 CIMR-ZU*A Series - Monitor Data

Register No. Contents
000FH
Control Selection Setting
bit 0 Reserved
bit 1 PI Setpoint Input
bit 2, bit 3 Reserved
bit 4 PI2 Target Input (enables the setting from MEMOBUS/Modbus)
bit 5 to B Reserved
bit C Enable Terminal S5 Input for Broadcast Data
bit D Enable Terminal S6 Input for Broadcast Data
bit E Enable Terminal S7 Input for Broadcast Data
bit F Reserved
0010H to 001FH Reserved
u
Monitor Data
Monitor data can be read only.
Register No. Contents
0020H
Drive Status 1
bit 0 During Run
bit 1 During Reverse
bit 2 Drive Ready
bit 3 Fault
bit 4 Data Setting Error
bit 5 Multi-Function Contact Output 1 (terminal M1-M2)
bit 6 Multi-Function Contact Output 2 (terminal M3-M4)
bit 7 Multi-Function Contact Output 3 (terminal M5-M6)
bit 8 to D Reserved
bit E ComRef status
bit F ComCtrl status
0021H
Fault Contents 1
bit 0 Overcurrent (oC), Ground fault (GF)
bit 1 Overvoltage (ov)
bit 2 Drive Overload (oL2)
bit 3 Overheat 1 (oH1), Drive Overheat Warning (oH2)
bit 4, bit 5 Reserved
bit 6 PI Feedback Loss (FbL / FbH)
bit 7 EF to EF7: External Fault
bit 8
CPFoo: Hardware Fault (includes oFx)
bit 9 Motor Overload (oL1), Overtorque Detection 1 (oL3), Undertorque Detection 1 (UL3)
bit A Reserved
bit B Main Circuit Undervoltage (Uv)
bit C Undervoltage (Uv1), Control Power Supply Undervoltage (Uv2), Soft Charge Circuit Fault (Uv3)
bit D Output Phase Loss (LF), Input Phase Loss (PF)
bit E MEMOBUS/Modbus Communication Error (CE), Option Communication Error (bUS)
bit F Operator Connection Fault (oPr)
E.9 MEMOBUS/Modbus Data Table
YASKAWA SIEP YAIZ1U 03B YASKAWA AC Drive – Z1000 Programming Manual
317
E
MEMOBUS/Modbus Communications
