YASKAWA Z1000 CIMR-ZU*A Series - Analog Input Objects; Analog Output Objects; Analog Value Objects

Property
Object Type
Device
Analog
Input
Analog
Output
Analog
Value
Binary
Output
Binary
Output
Binary
Value
Inactive_Text – – – – Yes Yes Yes
Active_Text – – – – Yes Yes Yes
<1> For Commandable Object Instances only.
u
Analog Input Objects
Table B.5 Analog Input Objects
Object ID Object Name
Modbus
Address
Precision Range Units PV Access
AI1 Analog Input 1 Level 004EH XXXX.X – % R
AI2 Analog Input 2 Level 004FH XXXX.X – % R
AI3 Not used – – – – –
AI4 Not used – – – – –
AI5 Not used – – – – –
AI6 Display Format o1-03 0502H XXXXX – – R
AI7 Scale Format b5-20 01E2H XXXXX – – R
AI8 Inverter Model o2-04 0508F XXXXX – – R
AI9 Rated Current n9-01 05D0H XXXX.X – Amps R
u
Analog Output Objects
Table B.6 Analog Output Objects
Object ID Object Name
Modbus
Address
Precision Range Units PV Access
AO1 Analog Output 1 Level 0007H XXXX.X 0 to 100.0 % C
AO2 Analog Output 2 Level 0008H XXXX.X 0 to 100.0 % C
u
Analog Value Objects
Table B.7 Analog Value Objects
Object ID Object Name
Modbus
Address
Precision Range Units PV Access
AV1 Not used – – – – –
AV2 Frequency Command 0002H
XXX.XX
Depends on
o1-03
0.00 to 600.00
Hz
Depends on
o1-03
C
AV3 PI Setpoint 0006H XXX.XX 0.00 to 100.00 % C
AV4 Not used – – – – –
AV5 Not used – – – – –
AV6 Not used – – – – –
AV7 Not used – – – – –
AV8 Not used – – – – –
AV9 Frequency Reference 0040H
XXX.XX
Depends on
o1-03
–
Hz
Depends on
o1-03
R
AV10 Output Frequency 0041H
XXX.XX
Depends on
o1-03
–
Hz
Depends on
o1-03
R
AV11 Output Voltage 0045H XXXX.X – Volts R
B.7 BACnet Objects Supported
YASKAWA SIEP YAIZ1U 03B YASKAWA AC Drive – Z1000 Programming Manual
257
B
BACnet Communications
