YASKAWA Z1000 CIMR-ZU*A Series User Manual

n
T1-07: Motor Base Speed
Sets the motor rated speed according to the motor nameplate value. Enter the speed at base frequency when using a motor
with an extended speed range or if using the motor in the field weakening area.
No. Name Setting Range Default
T1-07 Motor Base Speed 0 to 14400 r/min 1750 r/min
n
T1-11: Motor Iron Loss
Provides iron loss information to determine the Energy Saving coefficient. T1-11 will first display the value for the motor iron
loss that the drive automatically calculated when the motor capacity was entered to T1-02. Enter the motor iron loss value
listed to T1-11 if the motor test report is available.
No. Name Setting Range Default
T1-11 Motor Iron Loss 0 to 65535 W 14 W
n
T1-12: T1 Tuning Start
Set T1-12 to 0 to start IM Auto-Tuning.
No. Name Setting Range Default
T1-12 T1 Tuning Start 0 –
u
T2: Parameter Settings during PM Motor Auto-Tuning
The T2-oo parameters are used to set the Auto-Tuning input data for PM motor tuning.
n
T2-01: PM Motor Auto-Tuning Mode Selection
No. Name Setting Range Default
T2-01 PM Motor Auto-Tuning Mode Selection 0 0
Setting 0: PM Motor Parameter Settings
n
T2-03: PM Motor Type
Selects the type of PM motor the drive will operate.
No. Name Setting Range Default
T2-03 PM Motor Type 0, 1 1
Setting 0: IPM motor
Setting 1: SPM motor
n
T2-04: PM Motor Rated Power
Specifies the motor rated power in kilowatts.
No. Name Setting Range Default
T2-04 PM Motor Rated Power 0.00 to 650.00 kW
Determined by o2-04
and C6-01
n
T2-05: PM Motor Rated Voltage
Sets the motor rated voltage.
No. Name Setting Range Default
T2-05 PM Motor Rated Voltage 0.0 to 733.1 V 575.0 V
1.12 T: Motor Tuning
YASKAWA SIEP YAIZ1U 03B YASKAWA AC Drive – Z1000 Programming Manual
155
1
Parameter Details

YASKAWA Z1000 CIMR-ZU*A Series Specifications

General

Series	Z1000 CIMR-ZU*A Series
Category	Controller
Voltage Classes	200V, 400V
Enclosure	NEMA 1, NEMA 12
Frequency Range	0.01 to 400 Hz
Cooling Method	Fan Cooled
Operating Temperature	-10°C to 50°C
Application	HVAC
Control Method	V/f Control
Input Voltage	200-240V, 380-480V
Frequency Range (Input)	50/60 Hz
Power Rating	0.4kW to 630kW
Protection Features	Overcurrent, Overvoltage, Undervoltage
Communication Options	Modbus
Storage Temperature	-20°C to 60°C
Humidity	5% to 95% (non-condensing)
Enclosure Rating	IP20
Output Voltage	0-100% of input voltage
