A.16 Control Mode Dependent Parameter Default Values
The tables below list parameters that depend on the control mode selection. Changing the control mode initializes these
parameters to the values shown here.
u
A1-02 (Motor Control Mode) Dependent Parameters
Table A.3 A1-02 (Motor Control Mode) Dependent Parameters and Default Values
No. Name Setting Range Resolution
Control Modes (A1-02)
V/f (0) OLV/PM (5)
b3-08
Current Control Gain during Speed Search (Speed
Estimation Type)
0.00 to 6.00 0.01
<1>
0.30
C2-01 S-Curve Characteristic at Accel Start 0.00 to 10.00 0.01 s 0.20 1.00
C4-01 Torque Compensation Gain 0.00 to 2.50 0.01 1.00 0.00
C4-02 Torque Compensation Primary Delay Time 0 to 60000 1 ms 200 100
C6-02 Carrier Frequency Selection 1 to 9; A to F 1
<1>
2
E1-04 Maximum Output Frequency 40.0 to 240.0 0.1 Hz
<2>
60.0
E1-05 Maximum Voltage 0.0 to 733.1 0.1 V
<2>
200.0
E1-06 Base Frequency 0.0 to 240.0 0.1 Hz
<2>
60.0
E1-09 Minimum Output Frequency 0.0 to 240.0 0.1 Hz
<2>
3.0
L1-01 Motor Overload Protection Selection 0, 1, 4 1 1 4
L3-20 DC Bus Voltage Adjustment Gain 0.00 to 5.00 0.01 1.00 0.65
L8-38 Carrier Frequency Reduction Selection 0 to 2 1
<1>
0
L8-40 Carrier Frequency Reduction Off-Delay Time 0.00 to 2.00 0.01 s 0.50 0.00
<1> Default setting is dependent on parameter o2-04, Drive Model Selection.
<2> Default setting is dependent on parameter E1-03, V/f Pattern Selection.
