YASKAWA Z1000 CIMR-ZU*A Series User Manual

u
Recommended Cable
Table C.2 APOGEE FLN Cable Specifications
Secification Description
Cable configuration Twisted shielded pair
Gauge
Stranded wire: 0.2 to 1.0 mm
2
(24 to 16 AWG)
Sold wire: 0.2 to 1.5 mm
2
(24 to 16 AWG)
Wire lay Minimum 6 twists per foot
Shields 100% foil with drain wire
NEC type UL type CMP
Temperature
-10 °C to +40 °C IP20/NEMA 1, UL Type 1 Enclosure, External Heatsink
-10 °C to +50 °C IP00/Open Type Enclosure
Note: Cable lengths cannot exceed 152 m (500 feet) at 4800 baud.
C.3 Connecting to a Network
272
YASKAWA SIEP YAIZ1U 03B YASKAWA AC Drive – Z1000 Programming Manual

YASKAWA Z1000 CIMR-ZU*A Series Specifications

General

Series	Z1000 CIMR-ZU*A Series
Category	Controller
Voltage Classes	200V, 400V
Enclosure	NEMA 1, NEMA 12
Frequency Range	0.01 to 400 Hz
Cooling Method	Fan Cooled
Operating Temperature	-10°C to 50°C
Application	HVAC
Control Method	V/f Control
Input Voltage	200-240V, 380-480V
Frequency Range (Input)	50/60 Hz
Power Rating	0.4kW to 630kW
Protection Features	Overcurrent, Overvoltage, Undervoltage
Communication Options	Modbus
Storage Temperature	-20°C to 60°C
Humidity	5% to 95% (non-condensing)
Enclosure Rating	IP20
Output Voltage	0-100% of input voltage
