YASKAWA Z1000 CIMR-ZU*A Series User Manual

n
S2-03/S2-08/S2-13/S2-18: Sequence Timers 1 to 4 Day Selection
Sets the days for which sequence timers 1 to 4 are active.
No. Name Setting Range Default
S2-03 Sequence Timer 1 Day Selection 0 to 10 0
S2-08 Sequence Timer 2 Day Selection 0 to 10 0
S2-13 Sequence Timer 3 Day Selection 0 to 10 0
S2-18 Sequence Timer 4 Day Selection 0 to 10 0
Setting 0: Timer Disabled
Setting 1: Daily
Setting 2: Mon - Fri
Setting 3: Sat - Sun
Setting 4: Monday
Setting 5: Tuesday
Setting 6: Wednesday
Setting 7: Thursday
Setting 8: Friday
Setting 9: Saturday
Setting 10: Sunday
n
S2-04/S2-09/S2-14/S2-19: Sequence Timers 1/2/3/4 Selection
Sets the action that occurs when sequence timers 1 to 4 are active.
Note: 1. Setting 3 is available in drive software versions PRG: 8552 and later.
2. Setting 3 is not available in drive models 4A0930 and 4A1200.
No. Name Setting Range Default
S2-04 Sequence Timer 1 Selection 0 to 3 0
S2-09 Sequence Timer 2 Selection 0 to 3 0
S2-14 Sequence Timer 3 Selection 0 to 3 0
S2-19 Sequence Timer 4 Selection 0 to 3 0
Setting 0: Digital Output Only
Setting 1: Run
Setting 2: Run - PI Disable
Setting 3: Allow Alternation
When Sequence Selection is set to Allow Alternation and that timer is enabled (S2-03, S2-08, S2-13, S2-18 > 0), the drive
will only allow MEMOBUS alternation to occur during the time specified in the corresponding Sequence Timer. Alternation
is disabled when the timer deactivates.
n
S2-05/S2-10/S2-15/S2-20: Sequence Timers 1/2/3/4 Reference Source
Selects the frequency reference source used for running the drive when sequence timers 1 to 4 are active (only applicable when
S2-04/S2-09/S2-14/S2-19 are set to 1 or 2).
Note:
H1-oo = 12/13 overrides these sequence timer run sources in drive software versions PRG: 1018 and later.
No. Name Setting Range Default
S2-05 Sequence Timer 1 Reference Source 0 to 6 0
S2-10 Sequence Timer 2 Reference Source 0 to 6 0
S2-15 Sequence Timer 3 Reference Source 0 to 6 0
S2-20 Sequence Timer 4 Reference Source 0 to 6 0
1.11 S: Special Parameters
YASKAWA SIEP YAIZ1U 03B YASKAWA AC Drive – Z1000 Programming Manual
139
1
Parameter Details

YASKAWA Z1000 CIMR-ZU*A Series Specifications

General

Series	Z1000 CIMR-ZU*A Series
Category	Controller
Voltage Classes	200V, 400V
Enclosure	NEMA 1, NEMA 12
Frequency Range	0.01 to 400 Hz
Cooling Method	Fan Cooled
Operating Temperature	-10°C to 50°C
Application	HVAC
Control Method	V/f Control
Input Voltage	200-240V, 380-480V
Frequency Range (Input)	50/60 Hz
Power Rating	0.4kW to 630kW
Protection Features	Overcurrent, Overvoltage, Undervoltage
Communication Options	Modbus
Storage Temperature	-20°C to 60°C
Humidity	5% to 95% (non-condensing)
Enclosure Rating	IP20
Output Voltage	0-100% of input voltage
