S3-08: Secondary PI Integral Limit Setting
Sets the maximum output possible from the integrator.
No. Name Setting Range Default
S3-08 Secondary PI Integral Limit Setting 0.0 to 100.0% 100.0%
n
S3-09: Secondary PI Output Upper Limit
Sets the maximum output possible from the secondary PI controller.
No. Name Setting Range Default
S3-09 Secondary PI Output Upper Limit 0 to 100.0% 100.0%
n
S3-10: Secondary PI Output Lower Limit
Sets the minimum output possible from the secondary PI controller.
No. Name Setting Range Default
S3-10 Secondary PI Output Lower Limit -100.00 to 100.00 0.00%
n
S3-11: Secondary PI Output Level Selection
Sets the secondary PI controller output direction.
No. Name Setting Range Default
S3-11 Secondary PI Output Level Selection 0 or 1 0
Setting 0: Normal Output (Direct Acting)
Setting 1: Reverse Output (Reverse Acting)
n
S3-12: Secondary PI Disable Mode
Selects the secondary PI controller output when disabled.
No. Name Setting Range Default
S3-12 Secondary PI Disable Mode 0 to 2 0
Setting 0: No Output (0%)
Setting 1: Lower Limit (S3-10)
Setting 2: Setpoint
n
S3-13: Secondary PI Low Feedback Detection Level
Sets the secondary PI low feedback detection level.
No. Name Setting Range Default
S3-13 Secondary PI Low Feedback Detection Level
0.00 to 600.00
<1>
0.00
<2>
<1> Upper limit is S3-02, decimal place holder is determined by S3-03.
<2> Unit is determined by S3-04.
1.11 S: Special Parameters
142
YASKAWA SIEP YAIZ1U 03B YASKAWA AC Drive – Z1000 Programming Manual

YASKAWA Z1000 CIMR-ZU*A Series Specifications

General

Series	Z1000 CIMR-ZU*A Series
Category	Controller
Voltage Classes	200V, 400V
Enclosure	NEMA 1, NEMA 12
Frequency Range	0.01 to 400 Hz
Cooling Method	Fan Cooled
Operating Temperature	-10°C to 50°C
Application	HVAC
Control Method	V/f Control
Input Voltage	200-240V, 380-480V
Frequency Range (Input)	50/60 Hz
Power Rating	0.4kW to 630kW
Protection Features	Overcurrent, Overvoltage, Undervoltage
Communication Options	Modbus
Storage Temperature	-20°C to 60°C
Humidity	5% to 95% (non-condensing)
Enclosure Rating	IP20
Output Voltage	0-100% of input voltage
